Water Ionizer：Alkaline Ionized Water Device ET-800S
| Model | Alkaline Ionized Water Device ET-800S | |
|---|---|---|
| Type | Medical Device (83) Medical Substance Generator (JAPAN) | |
| Generic Name | Continuous Alkaline Ionized Water Device (JMDN code 70124000) (JAPAN) | |
| Medical device certificate No. | 303AFBZX00032A01 (JAPAN) | |
| Power | AC 220 - 240V 50-60Hz | |
| Power consumption | Approx. 210W (Approx. 0.7W in standby) | |
| Main Unit |
Dimensions | (W)255mm × (D) 130mm × (H) 335mm |
| Weight | 6kg (8kg for full water) | |
| Water supply specifications | Branched water tap (U shaped) | |
| Electrolysis method | Continuous electrolysis (with a built-in flow sensor) | |
| Maximum water temperature for continuous use | 40℃ or less (60℃ or less for switch cock) | |
| Usable water pressure for continuous use | Minimum | 0.1MPa (dynamic water pressure) |
| Maximum | 0.5 Mpa (dynamic water pressure) | |
| Filtration flow rate (at 0.1MPa) | 3.0L/minute | |
| Electrolytic | Flood water amount | Electrolyzed hydrogen water: Approximately 2.4 L / min, Acidic water: Approximately 0.6 L / min * When purifying water: Approximately 2.4 L / min (water discharged from the switching cock) |
| Water discharge ratio | (Ratio/ Primary: Secondary) 8:2 (Amount/Min) Primary is 2.4L Secondary is 0.6L(Dynamic water pressure 0.1Mpa) |
|
| Number of electrodes | Platinum-coated titanium electrodes (7 pieces) | |
| Electrolysis level | 8 types (Hydrogen water: 5 levels, acidic water: 2 levels, filtered water) | |
| Continuous usable time | 10 minutes in normal mode (5 minutes in strong mode) | |
| Lifespan of electrode plate | 1000 hours (with plate electrode lifespan and pH value of Hydrogen water at 9.5 as reference) | |
| Electrode cleaning method | Automatic cleaning (30 seconds) and manual cleaning (any 60 seconds) | |
| Voice announcement | Four languages (Japanese, English, Mandarin, and Cantonese) | |
| Liquid crystal screen | 7 background colors, pH, ORP, hydrogen-rich level, water flow, filter cartridge lifespan, timer, clock | |
| Water purification filter (LF-C1A) |
Types of filter media | Antibacterial activated carbon molded with silver-impregnated, Non-woven fabric |
| Water purification capacity (It is the value of 80% removal rate obtained by the test in JIS S 3201, * is the value of 50% of the filtration flow rate) | Free chlorine12,000L Turbid components＊12,000L Total trihalomethanes12,000L Chloroform 12,000L Bromodichloromethane12,000L Dibromochloromethane 12,000L Bromoform12,000L Tetrachlorethylene12,000L Trichloroethylene12,000L CAT (pesticide)12,000L 2-MIB (musty taste)12,000L Soluble lead12,000L |
|
| Substances that can be removed in addition to the above (value of 80% removal rate obtained by the test in the specifications specified by the Water Purifier Association (JWPA) | Geosmin (musty taste) 12,000L Phenols 12,000L Anionic surfactant 12,000L |
|
| Estimated time to replace the filter | About one year (30L is used per day) | |
| Reminder of filter cartridge replacement period | When the water flow reaches 11000L and 12000L respectively, a notice will be given out through the machine screen and voice announcement. | |
| Protective device | Current fuse | |
Water Ionizer：Residential use HU-150
| Model | Human Water HU-150 | |
|---|---|---|
| Power | AC100V 2.0A 50/60Hz | |
| Power consumption | 240W (Max) 0W (Standby) | |
| Main Unit |
Dimensions | (W)270mm × (D) 130mm × (H) 250mm |
| Weight | About 5.2kg (when Full) About 4.8kg (when dry) | |
| Water supply specifications | Switching cock connection 3-stage switching type (built-in hot water stopper and pressure relief valve) | |
| Electrolysis method | Continuous electrolysis method (built-in flow sensor) | |
| Maximum water temperature for continuous use | 35℃ | |
| Maximum water pressure for continuous use | 0.5 MPa | |
| Electrolytic | Flood water amount | Electrolyzed hydrogen water: Approximately 3.2 L / min, Acidic water: Approximately 0.8 L / min * When purifying water: Approximately 3.2 L / min (water discharged from the switching cock) |
| Water discharge ratio | hydrogen water: acidic water 4: 1 | |
| Electrolysis level | 3 stages (electrolysis mode: flow rate tracking (standard)+ constant current) 6 stages in total | |
| Continuous usable time | About 30 minutes (standard) About 10 minutes (when electrolytic level is strong and constant current mode is set) | |
| Electrode cleaning method | Reverse electric cleaning according to the integrated electrolysis time (5 minutes) | |
| Filtration flow rate (at 0.1MPa) | 4.0L / min | |
| Minimum usable water pressure | 0.1MPa | |
| Water purification filter (HUR-K) |
Types of filter media | Activated carbon, ceramic, hollow fiber membrane, non-woven fabric |
| Water purification capacity (total filtration flow rate) |
Free residual chlorine 12,000L Turbidity 7,000L Soluble lead 7,000L CAT (pesticide) 7,000L 2-MIB (moldy odor) 7,000L Total trihalomethane 7,000L Chloroform 7,000L Bromodichloromethane 7,000L Dibromochloromethane 7,000L Bromoform 7,000L Tetrachlorethylene 7,000L Trichlorethylene 7,000L |
|
| Estimated time to replace the filter | About 12 months (based on free residual chlorine) for using about 33L per day | |
| Protective device | Current fuse | |
Water Ionizer: Residential Use NDX-501LM “Alkali”
| Model | NDX-501LM | |
|---|---|---|
| Power | AC100V 2.0A 50/60Hz | |
| Power consumption | 180W(Max) 3.6W（Standby） | |
| Main Unit |
Dimensions | (W)335mm × (D) 100mm × (H) 240mm |
| Weight | About 3.6kg (when Full) About 3.2kg (when dry) | |
| Filter | Dimensions | (W)108mm × φ89mm × (H) 272mm |
| Weight | About 2.0kg (when Full) About 1.2kg (when dry) | |
| Callan | Dimensions | (W)60mm × (D)190mm × (H) 310mm |
| Water supply specifications | Opening and closing by lever operation of callan (lever faucet) (water supply pipe connection) | |
| Electrolysis method | Continuous electrolysis method (built-in flow sensor) | |
| Maximum water temperature for continuous use | 35℃ | |
| Maximum water pressure for continuous use | 0.5MPa(Be sure to install the attached pressure reducing valve) | |
|
Electrolytic (when electrolyzed hydrogen water is selected) |
Water discharge amount (When installing the attached pressure reducing valve) |
Electrolyzed hydrogen water: Approximately 3.2 L / min, Acidic water: Approximately 0.8 L / min (± 10%) * When purifying water, approx. 3.2 L / min (± 10%) (water discharge amount on the top tap side) |
| Water discharge ratio | hydrogen water: acidic water 4: 1 | |
| Electrolysis level | 3 stages (electrolysis mode: flow rate tracking (standard)+ constant current) 6 stages in total | |
| Continuous use | About 30 minutes (standard) | |
| Possible time | About 10 minutes (strong electrolytic level (3), when constant current mode is set) | |
| Electrode cleaning method | Reverse electric cleaning according to the integrated electrolysis time (5 minutes) | |
| Electrolytic cell life | 1200 Hours | |
|
Water purification filter (AR501K) |
Filtration flow rate | 4.0L / min * At 0.1MPa |
| Minimum dynamic water pressure | 0.1MPa * Minimum usable water pressure | |
| Types of filter media | Activated carbon, ceramics, hollow fiber membranes, non-woven fabrics. | |
| Water purification capacity | Free residual chlorine 12,000L Turbidity12,000L Soluble lead6,000L CAT (pesticide)6,000L 2-MIB (moldy odor)6,000L Total trihalomethane6,000L Chloroform6,000L Bromodichloromethane6,000L Dibromochloromethane6,000L Bromoform6,000L Tetrachlorethylene6,000L Trichlorethylene6,000L |
|
|
Other than the above Substances that can be removed |
Iron (fine particles) Aluminum (neutral) |
|
| Estimated time to replace the filter media |
About 12 months (free residual chlorine) when using about 33L per day (The replacement period varies depending on the substance to be removed. Also, the amount of water used, Depending on the water quality and pressure, the guideline for replacement time may be shorter.) |
|
| Calcium addition | 0None * Possible by installing optional products (electrolytic aid) | |
| Protective device | Current fuse 6.3A (mounted on the board) | |
Water Ionizer: Residential Use HU-80 “Human water”
| Model | Human Water HU-80 | |
|---|---|---|
| Power | AC100V 2.0A 50/60Hz | |
| Power consumption | 240W (Max) 0W (Standby) | |
| Main Unit |
Dimensions | (W)270mm × (D) 150mm × (H) 250mm |
| Weight | About 5.2kg (when Full) About 4.8kg (when dry) | |
| Water supply specifications | Switching cock connection 3-stage switching type (built-in hot water stopper and pressure relief valve) | |
| Electrolysis method | Continuous electrolysis method (built-in flow sensor) | |
| Maximum water temperature for continuous use | 35℃ | |
| Maximum water pressure for continuous use | 0.5 MPa | |
| Electrolytic | Flood water amount | Electrolyzed hydrogen water: Approximately 3.2 L / min, Acidic water: Approximately 0.8 L / min * When purifying water: Approximately 3.2 L / min (water discharged from the switching cock) |
| Water discharge ratio | hydrogen water: acidic water 4: 1 | |
| Electrolysis level | 3 stages (electrolysis mode: flow rate tracking (standard)+ constant current) 6 stages in total | |
| Continuous usable time | About 30 minutes (standard) About 10 minutes (when electrolytic level is strong and constant current mode is set) |
|
| Electrode cleaning method | Reverse electric cleaning according to the integrated electrolysis time (5 minutes) | |
| Filtration flow rate (at 0.1MPa) | 4.0L / min | |
| Minimum usable water pressure | 0.1MPa | |
| Water purification filter (HUR-K) |
Types of filter media | Activated carbon, ceramic, hollow fiber membrane, non-woven fabric |
| Water purification capacity (total filtration flow rate) |
Free residual chlorine 12,000L Turbidity 7,000L Soluble lead 7,000L CAT (pesticide) 7,000L 2-MIB (moldy odor) 7,000L Total trihalomethane 7,000L Chloroform 7,000L Bromodichloromethane 7,000L Dibromochloromethane 7,000L Bromoform 7,000L Tetrachlorethylene 7,000L Trichlorethylene 7,000L |
|
| Estimated time to replace the filter | About 12 months (based on free residual chlorine) for using about 33L per day | |
| Protective device | Current fuse | |
Water Ionizer ： Residential Use HU-121 ”Human Water”
| Model | Human Water HU-121 | |
|---|---|---|
| Power | AC100V 2.4A 50/60Hz | |
| Power consumption | 240W (Max) 1.5W (waiting) | |
| Device type | Implement/Machine(83) Material Generator of Medical Devices | |
| General name of device | Continuous Electrolysis Water Generator | |
| Main Body |
Dimensions | (W)240mm × (D) 140mm × (H) 305mm |
| Weight | Approx 6.3kg (Full) Approx 5.5kg (Empty) | |
| Water delivery method | Switching Valve Faucet | |
| Electrolysis Type | Continuous electrolysis system (sensor of water flowing) | |
| Max temp. of continuous use | 35℃ | |
| Max pressure of continuous use | 0.5 MPa | |
| Protection System | Fuse 6.3A(included) | |
Water Ionizer：Residential use NDX-303LMW
| Model | Alka-Rich NDX-303LMW | ||
|---|---|---|---|
| Power | AC100V 2.4A 50/60Hz | ||
| Power consumption | 250W (Max) 3.6W (waiting) | ||
| Device type | Implement/Machine(83) Material Generator of Medical Devices | ||
| General name of device | Continuous Electrolyzed Water Generator | ||
| Number of medical device | 223AFBZX00047000 (Controlled medical device) | ||
| Main Body |
Dimensions | W335mm×H242mm×D100mm | |
| Weight | Approx 4.2kg (Full) Approx 3.8kg (Empty) | ||
| Cartridge | Dimensions | W108mm×H272mm×D89mm | |
| Weight | Approx 2.0kg (Full) Approx 1.2kg (Empty) | ||
| Faucet | Dimensions | W45mm×H340mm×D190mm | |
| Water delivery method | Opening and closing of solenoid valve by controlling electronic faucet. | ||
| Electrolysis Type | Continuous electrolysis system (sensor of water flowing) | ||
| Max temp. of continuous use | 35℃ | ||
| Max pressure of continuous use | 0.5 MPa (necessary install included decompression valve) | ||
| Electrolysis (Alkaline) | Amount of Generated water | Water pressure 0.2MPa | Alkaline: approx 3.3L/min Acid: approx0.7/min Purified water: approx 4.0/min (only top-tap) |
| Water pressure 0.1MPa | Alkaline: approx 2.6L/min Acid: approx0.6/min Purified water: approx 3.2/min (only top-tap) |
||
| Ratio of Generating water | Alkaline : Acid 4.5 : 1 |
||
| Range of Eelectrolysis | Normal: 3 levels (standard mode and constant current) Total: 6 levels |
||
| Limit of Continuous use | Approx 30 minutes (normal) Approx 10 minutes (strong electrolysis level and constant current) |
||
| Electrodes Cleaning system | Flip-Flop method | ||
| Life Duration of Electrolysis Chamber | 800 hours | ||
| Replacement Cartridge（AR303K） | Capacity Amount of Filtration | Approx 4.0L/min | |
| Minimum Dynamic Water Pressure | 0.1 MPa | ||
| Filter media | Activated carbon, Ceramic, Hollow Fiber Membrane, Nonwoven Fabric |
||
| Function (*1)(Total Amountof Filtration) | Residual chlorine12,000L Turbidity12,000L Soluble lead6,000L Agrichemical (CAT)6,000L Mold odor (2-MIB)6,000L All trihalomethane6,000L Chloroform6,000L Bromodichloromethane6,000L Dibromochloromethane6,000L Bromoform6,000L Tetrachloroethylene6,000L Trichloroethylene6,000L I,I,I-trichloroethylene6,000L |
||
| Replacement of filter (*2) | Approx 12 months in case that it is used 33L per day. (residual chlorine) Duration would be changed by the amount of water and the quality of water. |
||
| Addition of the calcium | Additional method of mandatory diffluence system Additional pipe is installed. |
||
| Protection System | Fuse 6.3A(included) | ||
(*1) The value which is 80% of removal ratio is based on the testing method of water purifier for home use (JIS S 3201) and the value that is 50% of the amount of filtration is about turbidity.
(*2) It is necessary to change the Filter Cartridge once a year to keep its ability.
Water Ionizer: Residential Use HU-90 “Human water”
| Model | Human Water HU-90 | |
|---|---|---|
| Power | AC100V 2.4A 50/60Hz | |
| Power consumption | 240W (Max) 3.0W (Standby) | |
| Main Unit |
Dimensions | (W)240mm × (D) 140mm × (H) 305mm |
| Weight | About 6.3kg (when Full) About 5.5kg (when dry) | |
| Water supply specifications | Switching cock connection 3-stage switching type (built-in hot water stopper and pressure relief valve) Return method | |
| Electrolysis system | DEM(Dual Electrolysis Mode) system | |
| Maximum water temperature for continuous use | 35℃ | |
| Maximum water pressure for continuous use | 0.5 MPa | |
| Electrolytic | Flood water amount |
Electrolyzed hydrogen water: Approximately 3.2 L / min, Acidic water: Approximately 0.8 L / min * When purifying water: Approximately 3.2 L / min (water discharged from the switching cock) |
| Water discharge ratio | hydrogen water: acidic water 4: 1 | |
| Electrolysis level | 3 stages (electrolysis mode: flow rate tracking (standard) + constant current) 6 stages in total | |
| Continuous usable time | About 30 minutes (standard) About 10 minutes (when electrolytic level is strong and constant current mode is set) |
|
| Electrode cleaning method | ECO（Effective Cleaning Operation）system | |
| Filtration flow rate (at 0.1MPa) | (3.2～)4.0L / min | |
| Minimum usable water pressure | 0.1MPa | |
| Water purification filter (HUR-K) |
Types of filter media | Activated carbon, ceramic, hollow fiber membrane, non-woven fabric |
| Water purification capacity (total filtration flow rate) |
Free residual chlorine 12,000L Turbidity12,000L Soluble lead6,000L CAT (pesticide)6,000L 2-MIB (moldy odor)6,000L Total trihalomethane6,000L Chloroform6,000L Bromodichloromethane6,000L Dibromochloromethane6,000L Bromoform6,000L Tetrachlorethylene6,000L Trichlorethylene6,000L |
|
| Estimated time to replace the filter | About 12 months (based on free residual chlorine) for using about 33L per day | |
| Protective device | Current fuse | |
Water Purifier：Residential Use TWIN-e
| Model | TWINe(Home-use water purifier:Counter-top type) | |
|---|---|---|
| Material | ABS plastic:Body and cartridge Polyethylene:Hose | |
| Filter media | Actuvated carbib abd hollow fiber membrane | |
| Mimuimum Water Pressure | 0.05MPa | |
| Filtration ability | Free residual chlorine Turibidness Total tnhalome thane Soluble lead CAT(agrichemical) 2-MIB(mold odor) |
Total filtration:15,000L(Removal rate 80%) Total filtration:24,000L(Removal rate 80%) Total filtration:6,000L(Removal rate 80%) Total filtration:6,000L(Removal rate 80%) Total filtration:6,000L(Removal rate 80%) Total filtration:6,000L(Removal rate 80%) |
| Cartridge replacement | Free residual chlorine Turibidness Total tnhalome thane Soluble lead CAT(agrichemical) 2-MIB(mold odor) |
12 months (41L/day) 12 months (65L/day) 12 months (16L/day) 12 months (16L/day) 12 months (16L/day) 12 months (16L/day) |
| ※Depending on object substance,amount of water quality. | ||
| Capacity of filtrations | 3.0L/min | |
| Range of water pressure | 0.1～0.7MPa | |
| Size | W232mm×H260mm×D120mm | |
Water Ionizer: Industrial Use NDX-3000LMW
| Dimensions | (W)802mm × (D) 510mm × (H) 1100mm |
|---|---|
| Weight | About 155kg (Electrolysis unit:55kg/Power unit:100kg) |
| Rating | AC200V(3-phase)/50A |
| Water discharge amount |
Alkaline ionized water 3,000L/H Acid ionized water 1,500L/H |
| Electrolysis capacity | pH adjustment 5 stages |
| Safety device |
Main breaker with earth-leakage circuit (sensitivity current30mA) Overcurrent protection circuit Circuit breaker 25A |
| pH |
Alkaline: pH 7.0~10.0 Acidic: pH 7.0~4.0 |
| Piping diameter | 30A（1¼"）water supply Alkaline ionized water Acid ionized water Drainage 20A(¾") |
| Electrode material | Titanium (platinum group surface treatment) Both anode(+) and cathode(-) |
Water Ionizer：Commercial unit NDX-360PLW / NDX-500PLW
| Model | NDX-360PLW | NDX-500PLW |
|---|---|---|
| Water Pressure | 0.2～0.75MPa | 0.2～0.75MPa |
| Water Temperature | 0～35℃(without freezing) | |
| Ambient Temperature | 0～40℃(without direct sun-lignt) | |
| Rating | AC100V 4.5A 50/60Hz | AC100V 6A 50/60Hz |
| Weight | Main body:19kg Purifier:8kg | Main body:22kg Purifier:8kg |
| Size | Main body:W350mm×H320mm×D250mm | Main body:W360mm×H350mm×D280mm |
| Purifier:W380mm×H360mm×D160mm | Purifier:W380mm×H360mm×D160mm | |
| Water Production | Alkaline:6.0L/min Acid:1.5L/min | Alkaline:8.4L/min Acid:2.1L/min |
| Electrolysis level | 5 levels(pH7.5～9.5)depends on the water quality | |
| Auto-cleaning system | Flip-flop system | |
| Auto-drain system | Auto-drain each 4 hours | |
| Filtration | Free residual chorine(2ppm):200,000L | Free residual chorine(2ppm):200,000L |
| Turbidty:450,000L | Turbidty:200,000L | |
| Filtration flow volume | 7.5L | 10.5L |
Ionized Alkaline water Vending Machine WS-01A “Water Station”
The view of "recycling" as for PET bottle has permeated to be considered. Now consumer is changing their mind from "recycling" to "returnable" at present.
Product which is returnable refers to the product which can be reused. Especially re-usable reservoir, package is quite important considering environment of the earth, "global warming issue".
Basic concept to develop this unit "Water Sattion" is considered to fit present environmental point of view, it means very important considering conservation of the environment.
| Model | WS-01A |
|---|---|
| Dimention | W650mm×D680mm×H1650mm |
| Weight | 135kg |
| Cover | SUS304 |
| Color | Silver |
| Electricity | AC 100V,50/60Hz |
| Water Tamperature | 0～35℃ |
| Ambient Tamperature | 0～40℃ |
| Ambient Humidity | 35～85%RH |
| pH | 8.5～9.3 |
| Flowing Water Pressure | 0.25～0.75MPa |
| Water Production | 4L/min |
| Operation | Card Reader type or Coin-operated type(option) |
| Safety | 1.Overcurrent protective device 2.Water leakage detection function 3.Electorysis cell overheat protection 4.Trans overheat protector |
| Sanitation device | 1.Pipe-cleaning with Sodium hypochlorite 2.UV germicidal lamp |
| Maintenance | 1.Chemical cleaning within the body …1/year 2.Filling a chemical for pice-cleaning …1/month |
